最新技術文件

Industrial Power Transmission Belts

Timing Belt

How to Install Timing Belts

Tension control is crucial for belt usage. Without proper tensioning, maintaining satisfactory power transmission and durability becomes impossible. This video explains how to install the timing belt.
Industrial Power Transmission Belts

Timing Belt

Stress-strain Curve

The elongation of a timing belt can be analyzed using a 'Stress-Strain Curve' graph. This graph illustrates the rate of elongation of the timing belt when the belt's teeth are engaged with the pulley's teeth, and a load is applied.
Industrial Power Transmission Belts

Timing Belt

Backlash of Timing Belt and Pulley

Backlash refers to the gap between the teeth of the timing belt and those of the timing pulley. The amounts of backlash for different tooth profiles are introduced below.
Industrial Power Transmission Belts

V-belt

V-belt Premature Failure and Troubleshooting

Factors Leading to Premature V-Belt Failure and Prevention Methods: Proper Usage Extends Service Life.
Industrial Power Transmission Belts

Timing Belt

Jumping Torque

"Jumping torque" refers to the maximum torque a belt system can withstand before tooth skipping occurs.
This phenomenon, also known as tooth skipping, is influenced by several factors.
Industrial Power Transmission Belts

Timing Belt

Noise Comparison

When running, the timing belt generates noise as it engages with the pulleys.
Narrowing the width of the belt has a significant effect in reducing this noise, and utilizing a high-torque timing belt designed with a narrower belt width can reduce noise."
Industrial Power Transmission Belts

Timing Belt

Premature Timing Belt Failure and Troubleshooting

When premature failure occurs, using the belt as it is may result in loss of functionality or damage to surrounding components due to belt breakage, etc. There are multiple factors that can cause premature belt failure, each with different countermeasures and treatment details.
Industrial Power Transmission Belts

Timing Belt

Bareback Timing Belt Specifications

Features of the bare-back type are introduced below. The bare-back type has specially treated tooth cloth, which enables clean operation with less rubber powder scattering.
